Recon Toolkit™
Accident Reconstruction Tools for Blender
Recon Toolkit™ turns recorded crash data — EDR reports, motion tables, survey points — into animated Blender scenes, and adds the measurement and visualization tools reconstructionists need to present motion clearly and defensibly.

Capabilities
- EDR importer / entry: animate from Time + Speed + Yaw Rate or Steering Wheel Angle (bicycle-model yaw, optional slip estimate), or follow a path with a speed profile
- Motion data importer: full pose per timestamp from Time, X, Y, Z, Roll, Pitch, Yaw rows
- Point importer: numbered, labelled survey markers, connected into polylines by description
- Flexible CSV import everywhere — headers auto-matched, unit-aware, every mapping overridable
- Motion path tools: generate, toggle, and convert motion paths to editable 3D curves
- Timed location markers along an animated object's motion, with time labels
- Scale objects to a known real-world distance between two survey points
- Speed and acceleration baking to animated properties for HUD-style readouts
What’s included
Your purchase provides access to the product’s repository and official update channel for the stated update term. It is not a proprietary software license; the installed add-on remains free software under the GNU GPL.
- Official Recon Toolkit™ software package — free
- Automatic updates through the EDC Software repository
- Official documentation
Who It's For
Accident reconstruction engineers and analysts who work from EDR downloads, total-station or drone survey data, and motion analysis — and need that data on screen as accurate, presentation-ready animation.
Requirements
- Blender 4.2 or newer
- Uses Blender's bundled Python — no extra installation
Latest version
v1.8.0 · released 2026-10-20 · delivered through the EDC Software repository with automatic update notifications in Blender.
What’s new
Added
- Each display box has its own collection. A box's root and its text and frame objects now go into a collection named after the box, a child of Data Display, rather than straight into Data Display with every other box. Exclude that collection in a view layer and only that box disappears there, so a box can be kept to the camera it was made for. A box built by an earlier version moves into its own collection the next time it is rebuilt. Removing a box removes its emptied collection too.
- Moving or scaling an attached display box by hand now sticks. Scale the box in the viewport and Screen Width Fraction follows; move it and Offset X and Y follow; push it along the camera's axis and Camera Distance follows. The box is then placed from those settings again, which squares an uneven scale and drops any rotation, and every other box on the same profile moves with it. Before, a hand edit held only until the next slider tick, rebuild or channel tick put the stored settings back over it.
Fixed
- Undo after Add Display Box crashed Blender. The operators that create, rebuild or delete the box objects, and the channel ticks and row buttons that rebuild them under Auto Update, pushed no undo step. Undo then restored the step before them over objects Blender had never recorded. Every Data Display operator that changes the scene now carries UNDO, so undo takes the step back cleanly. Add Display Box also gets an Adjust Last Operation panel to change its mode after the fact.
- A keyframed channel read as one unchanging number in a box whose Time Zero Frame was set. A speed bake is keyframed at absolute scene frames, and the box slid it by its Time Zero Frame as well, reading the curve that many frames early, off its own front, where an F-Curve holds flat. With Time Zero at impact a speed bake showed 0 on every frame while its curve plainly rose. Keyframed rows now take only their group's Zero Frame Offset. Timed entries and Data: meshes still follow the box's Time Zero Frame, which is what places their t=0.
- A box's values read as if its Time Zero had been lost when the HVE Toolkit was installed too. Both toolkits tag their display rows the same way, and each toolkit's frame handler wrote every row in the scene, the other toolkit's with its own import records and so without that import's Time Zero. Whichever handler ran last won, which after an update is the add-on enabled last. Each handler now leaves the other toolkit's boxes alone.
Install & updates
Your repository secret is delivered instantly — it appears on the confirmation page as soon as you check out (and free products issue one after a quick sign-up). Then, in Blender 4.2 or newer:
- Open Edit → Preferences → Get Extensions.
- Open the Repositories dropdown (top right) →
+ → Add Remote Repository, and paste
https://extensions.edccorp.com/index.json. - Enable "Requires Access Token" on that repository and paste the repository secret you received into the Secret field.
- Your products appear under Available — click Install.
- Make sure the add-on is enabled. Installing usually ticks its checkbox for you, but if the product's sidebar tab doesn't appear, open Edit → Preferences → Add-ons, search for the product, and tick its checkbox to activate it. Updates then arrive automatically.
- Save your preferences so this sticks. Blender normally saves them automatically; if it doesn't, open the ≡ menu at the bottom-left of the Preferences window and choose Save Preferences — otherwise you may have to re-enable the add-on next time you open Blender.
Upgrading from an older, manually-installed version of this add-on? You can disable or remove it anytime from Edit → Preferences → Add-ons — search for it, untick it to disable, or use Remove to uninstall. The new extension replaces it.
Because the installed add-on is GPL-licensed free software, copies you have already received remain yours to use, study, modify, and share under the GPL. When the update term ends, repository access for future official builds and automatic updates may require renewal.
